Product Introduction

This equipment is specifically designed for coal seam slot cutting and pressure relief operations in complex geological conditions in underground coal mines. It integrates ultra-high-pressure hydraulic cutting, coal seam water injection, gas drainage, and stress release. Utilizing modular hydraulic drive with a maximum pressure of 60 MPa, and equipped with an intelligent control system and explosion-proof structure, it precisely performs deep coal seam slot cutting, reducing stress concentration in the coal mass and mitigating gas outbursts. High-pressure water circulates to flush the borehole, remove coal debris, wet the coal seam, and improve ventilation and operational safety. The tracked chassis adapts to narrow roadways, while forced lubrication at the power end and multiple safety protection devices ensure long-term stable equipment operation. It is a key equipment for achieving efficient coal seam pressure relief, advanced gas control, and safe mining operations.

Product Parameters

Specifications
Parameter		Unit	Model
Parameter		Unit	KFSL-60-113
Integrated System	Slot Width	mm	80 ～ 120
	Water Consumption	L/min	125
	Arm Deployment Pressure	MPa	15
Clear Water Pump	Water Jet Rated Working Pressure	MPa	60
	Rated Working Pressure	MPa	100
	Rated Flow Rate	L/min	125
Drill Rig	Motor Power	kW	250
	Rated Torque	N·m	4600
	Rated Rotational Speed	r/min	60
	Dill Bit Diameter	mm	113
	Drill Pipe Diameter	mm	73
	Motor Power	kW	55
Dewatering Unit	Rated Working Pressure	MPa	18
	Processing Capacity	m³/h	50
	Motor Power	kW	15
