Xiangde News | Successful Delivery of 5 Coal Mine Tunnel Drilling Rigs!

Specialized Training on "New Equipment, New Processes, New Technologies" (Reposted from "Jinneng Holding Xinzhou Company Taishan Long'an Coal Industry")

Recently, Xiangde Electromechanical successfully delivered 5 coal mine tunnel drilling rigs to Jinneng Holding. Taishan Long'an Coal Industry’s water exploration team organized a specialized training session on "new equipment, new processes, new technologies" centered around the newly introduced "Xiangde ZDY4500LPS Coal Mine Tunnel Drilling Rig." As the research and development and supply partner for this equipment, Xiangde Electromechanical provided technical support. Through a dual approach of "theory + hands-on practice," the training aimed to help coal industry employees quickly master the equipment's operational skills, ensuring the new machinery achieves its full potential and injects robust momentum into the safe production of the coal mine.

Xiangde ZDY-LPS Coal Mine Tunnel Drilling Rig: Tailor-Made for Efficient Coal Mine Operations

• The drill rig features a compact structure and excellent flexibility, allowing it to adapt to various geological conditions.

• The horizontal drilling height of the rig is adjustable, enabling multi-layer drilling, cross-belt drilling, and large-angle drilling operations.

• The rig allows for inclination adjustment within a range of ±90° and azimuth adjustment from 0° to 360°.

• With high feed and pullback forces, the rig facilitates the handling of special conditions within boreholes.

• The rig utilizes a fully hydraulic system, ensuring simple operation and offering efficient, stable drilling and rotation functions for continuous drilling operations.

• Equipped with a load-sensing hydraulic system and proportional valve control, key hydraulic components such as pumps and valves operate with high efficiency, stability, and reliability.

• The rig supports independent adjustment of multiple linkage and rotation parameters as well as feed process parameters, enabling functions such as rapid drilling, rod retraction, and tripping.

• It incorporates multiple safety protection measures, including overpressure protection, electrical protection, and hydraulic self-locking, to ensure construction safety.

• The rig allows for the replacement of different models of chuck slips and holder slips to meet varying requirements for borehole diameter and depth.

• For horizontal drilling, the rig's height ranges from 1,325 mm to 2,500 mm; for -90° drilling, the frame height is 2.7 m, while for +90° drilling, the frame height is 2.76 m.

• The rig is optionally compatible with a remote controller, supporting remote operation for both movement and the entire drilling process.

• The rig’s control handles feature a visual design, with function buttons clearly distinguished by colors for quick identification. It is also equipped with mechanical locking devices and multiple protective designs to effectively prevent operational errors, further ensuring operational safety and stable equipment performance.

• Compatible drill rods: φ63.5 mm / 73 mm.

  Promoting Application Through Training, Enhancing Safety with Equipment

  The successful implementation of this specialized training has not only enabled the water exploration team to fully master the operation and maintenance skills of Xiangde drilling rigs but also highlighted Xiangde Electromechanical’s commitment to "empowering coal mine safety with technology." In the future, Xiangde Electromechanical will continue to deepen its research and innovation in coal mine electromechanical equipment, driving its products toward greater "customization, specialization, intelligence, and sustainability." The company aims to assist more coal mining enterprises in enhancing their equipment capabilities and operational efficiency, jointly advancing the safe and efficient development of the coal mining industry.
